Zoom MSH-6 - Mid-Side Microphone Capsule for Zoom H5 and H6 Field Recorders
The Zoom MSH-6 MS Capsule comes standard with the H6 Handy Recorder and can be used with the H5. Although the MSH-6 MS capsule appears to be just one microphone, it actually contains two mic elements, positioned directly on top of one another. One of the microphones inside the MSH-6 is unidirectional (that is, it is mostly sensitive to signal coming from directly in front, and less sensitive to signal coming from behind or from the sides) while the other is bi-directional (that is, it is mostly sensitive to signals coming from directly in front and directly behind, and less sensitive to signal coming from the sides).
Mid-Side recording is a technique that allows you to adjust the width of the stereo image after it has been recorded, making it especially useful for film, video and television projects. The basic concept behind MS recording is that the Mid microphone picks up signal coming from the center, while the Side microphone creates ambience and directionality by adding or subtracting information from either side.
The Mid-Side technique works well whenever you need a variable amount of room sound. It can also be used for studio recording, and its convenience and flexibility make it a good option for rehearsal and live concert recording as well. Another benefit is that it provides total mono compatibility, making it an excellent choice for stereo recordings that may eventually be played back in mono, such as TV broadcasts.
Inside the H6 MS capsule, the directional ("Mid") mic faces forwards while the bi-directional ("Side") mic is set perpendicular to it, as shown in the picture above.
- Mid Microphone Faces Forward
- Side Bi-Directional Microphone
- Enables Stereo Width Post Adjustment
- Studio, Live, Rehearsal, TV Broadcast
- Microphone Type
- Unidirectional and bi-directional
- -37 dB, 1 kHz at 1 PA (unidirectional) | -39 dB, 1 kHz at 1 Pa (bi-directional)
- Input Gain
- -∞ to 42.5 dB
- Max SPL Level
- 120 dB SPL (unidirectional) | 122 dB SPL (bi-directional)
