Panasonic HC-X20 4K Mobile Camcorder
The HC-X20 offers 20x optical zoom, 24.5mm wide angle for both UHD and FHD, 4K high-precision AF with new face detection and higher precision, 5-Axis HYBRID O.I.S.+, high brightness LCD, and more. For video recording, the camcorders support 4:2:2 10-bit 4K 30p/25p internal video recording and the new, high-efficiency HEVC codec. They have been equipped with a wide variety of recording formats for the best selections such as Super slow motion (120/100 fps) and VFR (2 to 60 fps).
Featuring Remarkable Optical Performance for Precise Shooting
The integrated lens offers a remarkably powerful, optical 20x zoom that ranges from 24.5mm* wide angle to 490mm* tele. i.ZOOM achieves 24x at 4K resolution, and 32x at FHD. The 4-Drive Lens System drives the four lens groups independently, thus achieving the optical 20x zoom and compact body size.
High-speed, High-precision AF Including Face Detection AF/AE
Superior focusing speed, stability and tracking performance for both 4K and Full-HD is achieved thanks to Face Detection AF/AE together with the precise focus lens drive. Face Detection AF/AE provides precise focusing and sufficient exposure for subjects. In addition, subject tracking with color recognition can be activated by just touching the LCD panel enabling precise tracking.
5-Axis HYBRID O.I.S.+ Enables Stable Image Acquisition
For both UHD and FHD modes, in addition to OIS (Optical Image Stabilization), Electronic Image Stabilization operates to detect and correct handshake in 5 axes, including rotational blurring. This provides strong correction under unstable conditions, such as low-angle and high-angle shooting. The Ball O.I.S. System reduces friction on the drive section, achieving delicate correction even for small-amplitude handshake. This produces beautiful images with suppressed handshake even at high, 20x optical zoom.
High-sensitivity 1.0-type (1.0-inch) 4K Sensor for Superb Image Quality
The 1.0-type (1.0-inch) MOS sensor (approximately 15.03 effective megapixels) is capable of recording at UHD (3840 x 2160) without cropping and offers a moderate depth of field and an excellent balance between image quality and sensitivity. The file format can be selected from versatile and easy-to-use MOV (QuickTime), MP4 and AVCHD.
High-Quality Recording with Versatile Modes
The camcorders support a variety of bit rates and formats to meet professional needs. Internal recording of UHD up to 29.98p/25p and FHD up to 59.94p/50p in 4:2:2 10-bit high quality is now possible. When set for 10-bit recording, the camcorder delivers 4K 60p 4:2:2 10-bit HDMI output, enabling high image quality capture with an external recorder. New, highly efficient HEVC recording (LongGOP/10-bit 4:2:0/MOV) is also supported for recording 59.94p at a high bit rate of 200 Mbps, in addition to MOV, MP4, and AVCHD file formats.
Super Slow Motion and VFR (2 to 60 fps)
The Super Slow Motion function records HD images at a high speed of 120 fps (59.94 Hz)/100 fps (50 Hz) to provide a slow-motion effect. The HC-X20 is also newly equipped with a VFR (variable frame rate) recording function that allows the change of frame rate setting in ten steps from 2 to 60 fps. This lets the user produce creative and expressive videos using techniques such as overcranking for a slow-motion effect and undercranking for a quick-motion effect.
Versatile Network Functions Expand the User's Workflow
The built-in Wi-Fi module enables Wi-Fi connectivity using only the main unit. The HC-ROP tablet/smartphone app enables wireless remote control, including camera settings and lens control.
HC-X20 can be connected to a wired LAN by using a USB Ethernet adapter (sold separately).
RTSP/RTP/RTMP/RTMPS-compatible FHD streaming enables direct connection and streaming of live concerts, sporting events, breaking news, etc. to Facebook, YouTube, etc. It is also now possible to record while streaming.
Functions and Designs Supporting Pro Camera Work
The 3.5-inch LCD monitor has a high resolution of approximately 2,760k dots, more than double that of the previous model*1, and realizes excellent visibility even in bright sunlight with twice the brightness compared to the previous model. The electrostatic touch panel also improves operability when selecting menus.
Since the 2,360K-dot tiltable viewfinder and LCD output simultaneously, the image being recorded can also be confirmed in the LCD monitor while viewing it on the EVF, thus improving work efficiency. Also, to support fast, accurate manual focusing, Focus Assist functions are equipped, including Expand, Peaking and Area Mode. For shooting in even darker conditions, commercially available IR lights are supported for IR (Infrared) Shooting.
The lens barrel features Triple Manual Rings for zoom, focus and iris operations. There are a total of 14 User buttons, nine on the body and five on the LCD touch panel. These User buttons can be allocated with desired functions.
The ND filter can be set to Clear, 1/4, 1/16 or 1/64. Gain selector and AWB selector are also provided. The controls are designed and engineered to meet the needs of video professionals.
The included battery is designed to be integrated into the camera, not protruding from it, and can provide approximately 4 hours and 25 minutes of continuous shooting.
Double SD Card Slot and UHD/FHD Dual Codec Recording
Two SD memory card slots are provided. The recording media switches automatically and seamlessly from Slot 1 to Slot 2. By changing a full SD card with a new SD card, images can be recorded continuously for many hours.
Unlimited Relay Recording: Data is recorded continuously by automatically switching the recording SD card from Slot 1 to Slot 2. By changing the full SD card with a new SD card, images can be recorded continuously for many hours.
Simultaneous Recording: Identical data is recorded onto cards in both slots in this highly redundant recording mode.
Background Recording: One SD card can be set in Slot 2 to record continuously, and another SD card can be set in Slot 1 to record necessary scenes by turning REC on and off.
48-kHz/24-bit High Resolution Linear PCM Audio Recording
+48V Phantom Power Supply/MIC/LINE Selectable XLR Audio Input with Manual Volume is equipped for each of 2 channels. Also supported is a 24-bit linear PCM system (MOV), 16-bit AAC (MP4), or Dolby Audio system (AVCHD) high-quality 2-channel audio recording.
Broadcast-grade Camera Image Adjustment Functions
16-Axis Independent Color Correction Function: Allows color matching of multiple cameras under the same lighting condition as well as creative image rendering.
Soft Skin: Makes skin colors appear softly and beautifully. Especially effective when recording the person up close.
Master Detail: Adjusts the overall degree of contour enhancement.
Scene File: Six sets of image quality settings are preset in scene files. Parameters in each set can be changed flexibly. One set can be saved in the main unit, and up to eight sets can be stored on an SD memory card.
8-Mode Gamma: Gamma setting can be selected from seven modes including two types of CINE-LIKE gamma. This allows the user to achieve the most suitable gradation according to the specific video production need.
- Up to UHD 4K60 Video with Live Streaming
- 15MP 1" MOS Sensor, 5-Axis Hybrid OIS+
- 20x Optical Zoom, 4K 24x/HD 32x i.Zoom
- Built-In Wi-Fi, 120 fps Slow Motion
- Handle with 2 x XLR Audio Inputs
- Built-In ND Filters, Wired Remote Option
- Up to 10-Bit UHD 4K60 4:2:0 & 4K30 4:2:2
- Records MP4, MOV, AVCHD to Dual SD Slots
- Wide 25.4mm Lens, 3.5" LCD Display
- High-Speed AF with Face Detection
- Sensor Resolution:
- Effective: 15.03 Megapixel
- Sensor Type:
- 1"-Type MOS Sensor
- Image Stabilization:
- Optical in Integrated Lens, 5-Axis (Video Only) Digital
- Built-In ND Filter:
- Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters
- Capture Type:
- Stills & Video
- EXPOSURE CONTROL
- Shutter Type:
- Electronic Global Shutter
- Shutter Speed:
- 1/8000 to 1/6 Second
- Precise Scan Rate Control:
- Minimum Illumination:
- 0.2 Lux at 1/30 Shutter Speed
- White Balance:
- 3200 to 15,000K | Presets: ATW, Auto
- INTERNAL VIDEO CAPTURE
- Variable Frame Rates:
- 1080p: 2 to 60 fps
- Recording Limit:
- Up to 1650 Minutes
- Broadcast Output:
- Built-In Microphone Type:
- Audio Recording:
- AVCHD: 2-Channel 16-Bit 48 kHz
- MP4: 2-Channel 16-Bit 48 kHz AAC Audio
- MOV: 2-Channel 24-Bit 48 kHz
- STILL IMAGE CAPTURE
- Image Sizes:
- 16:9 DCF / EXIF / JPEG - 3840 x 2160 | 1920 x 1080 | 1280 x 720
- Aspect Ratio:
- Image File Format:
- Media/Memory Card Slot:
- Dual Slot: SD/SDHC/SDXC (UHS-I)
- Video I/O:
- 1 x 1/8" / 3.5 mm TRRS A/V (Composite) Output | 1 x HDMI Output
- Audio I/O:
- 2 x XLR 3-Pin Microphone (+48 V Phantom Power) Input | 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output
- Power I/O:
- 1 x Barrel (11.4 to 12.6 VDC) Input
- Other I/O:
- 1 x 2.5 mm Sub-Mini Input | 1 x USB Type-C Input
- Wi-Fi 4 (802.11n), Wi-Fi (802.11b/g)
- Monitor Size:
- Monitor Resolution:
- 2,760,000 Dot
- Display Type:
- Articulating LCD
- Built-In Electronic (OLED)
- 1,770,000 Dot
- Focus Type:
- Auto and Manual Focus
- Focus Mode:
- Automatic, Manual Focus
- Battery Type:
- Panasonic AG-VBR Series
- Accessory Mount:
- 1 x Cold Shoe Mount
- 6.7 x 7.7 x 13.5" (With Protrusions)
- 4.4 lb (Body Only) | 5.3 lb (With Battery, Grip, Viewfinder)
